Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Luxing
  • Model Number: lzsh 0.6/1kv 4 core xlpe cable 70mm
  • Insulation Material: XLPE / PVC
  • Type: Low Voltage
  • Application: Construction
  • Conductor Material: Aluminum / Copper
  • Jacket: PVC / PE / Rubber
  • Product name: lzsh 0.6/1kv 4 core xlpe cable 70mm
  • Origine: China
  • Sheath colour: Black or required
  • Standard: BS 7870 or IEC 60502
  • Conductor: Copper
  • Insulation: XLPE/PVC
  • Outer jacket: PVC/PE/XLPE
  • Certification: ISO9001,CCC,CE
  • Rated Voltage: 0.6/1kv
  • Color: Customized

Packaging & Delivery

Packaging Details wooden drum/steel wooden drum/steel iron drum of lzsh 0.6/1kv 4 core xlpe cable 70mm
Delivery Time 15-20 working days

lzsh 0.6/1kv 4 core xlpe cable 70mm

Structure Figure :





Product Description

lzsh 0.6/1kv 4 core xlpe cable 70mm

Name: lzsh 0.6/1kv 4 core xlpe cable 70mmarmored electric power cable
Standard
: IEC60502, BS, DIN, ASTM, GB12706-2008 standard.
Voltage
: Up to 35KV
Conductor
: Copper
Insulation
: XLPE

Armoured : Steel Wire Armoured

Sheath : PVC / LSZH PVC
Cross Section
: Based on client's requirement

Color : As you request
Application
: Low Voltage Power Cable is used in fixed laying indoor and outdoor.
Package
:  Wooden Drum Package or Iron-wooden drum



PVC Insulation Electric Cable

TYPE

Description of Cable



Main Applications



CU core

AL core

VV

VLV

Copper/Aluminium core,PVC insulated,PVC sheathed power cable

Non-armoured PVC cable are suited for laying indoors,In cable trench,On cable racks and in pipes. Unable bear external pressures and tensions.

VY

VLY

Copper/Aluminium core,PVC insulated,PE sheathed power cable

VV22

VLV22

Copper/Aluminium core,PVC insulated,steel tape armored,PVC sheathed power cable

Steel-tape armoured PVC cables are suited for vertical burial.Can bear moderate positive pressures,Unable bear tension forces.

VV23

VLV23

Copper/Aluminium core,PVC insulated,steel tape armored,PE sheathed power cable

VV32

VLV32

Copper/Aluminium core,PVC insulated,thin steel wire armored,PVC sheathed power cable

Thin steel wire armoured PVC cables are used in case of great difference of levels or vertical installation and Can do vertical burial.Can bear moderate positive pressures and tension forces.

VV33

VLV33

Copper/Aluminium core,PVC insulated,thin steel wire armored,PE sheathed power cable

VV42

VLV42

Copper/Aluminium core,PVC insulated,thick steel wire armored,PVC sheathed power cable

Thick steel wire armoured PVC cables are suited for vertical installation and can be laid water or sea-bottom.Can bear greater positive pressures and tension forces.

VV43

VLV43

Copper/Aluminium core,PVC insulated,thick steel wire armored,PE sheathed power cable



 XLPE Insulated electric cable

China Type

Description

Application

Cu

Al

YJV

YJLV

XLPE insulation PVC sheath power cable (Cu/XLPE/PVC)

To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside

YJY

YJLY

XLPE insulation PE sheath power cable (Cu/XLPE/PE)

YJV22

YJLV22

 XLPE insulation, steel tape armor,  PVC sheath power cable

(Cu/XLPE/PVC/STA/PVC)

To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.

YJV23

YJLV23

XLPE insulation, steel tape armor,  PE sheath power cable

(Cu/XLPE/PVC/STA/PE)

YJV62

YJLV62

XLPE insulation,  no  magnetism steel tape armor,  PE sheath power cable

YJV32

YJLV32

XLPE insulation, thin steel-wire  armor,  PVC sheath power cable

(Cu/XLPE/PVC/SWA/PVC)

Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint

.

YJV72

YJLV72

XLPE insulation, have no the magnetism thick steel-wire  armor,  PVC sheath power cable

YJV42

YJLV42

XLPE insulation, thick steel-wire  armor,  PVC sheath power cable

Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.



ZR: Means Flame retardent

Type

Nominal  cross-sectional area

Single-core

2-core

3-core

4-core

5-core

YJV

ZR-YJV

YJLV

ZR-YJLV

1.5-800

1.5-300

1.5-300

1.5-300

1.5-300

YJV22

ZR-YJV22

YJLV22

ZR-YJLV22

10-800

4-300

4-300

4-300

4-300

YJV32

ZR-YJV32

YJLV32

ZR-YJLV32

10-800

4-300

4-300

4-300

4-300

Company Information

Shandong New Luxing Cable Co.,Ltd established in the year of 1999, The headquarter is located in Jinan City, the capital of Shandong province, Registered capital of USD16.5 million, Legal representative Wang Xiuzhen. Our factory is located in Linyi Economic Development ZoneCovering an area of more than 60 acres.

Video Show :



1)Company introduction: https://youtu.be/j-bfOk2gCFY



2)Copper wire stranded: https://youtu.be/QT-b7M9YkLw



3)Copper wire braided: https://youtu.be/3-fP1OOuPA4



4)Cabling machine: https://youtu.be/h6kE4ofeiWA



5)Armoured: https://youtu.be/Clu5e7LW_l8



6)Extruded pvc sheathed,insulation: https://youtu.be/3c93OxsKmBw



We Mainly Produce

300/500V 450/750V electrical wire

AAC conductor

600/1000V PVC insulated cable

AAAC conductor

600/1000V XLPE insulated cable

ACSR conductor

1.8/3KV to 26/35KV power cable

OPGW

Armored underground cable

ABC cable

Control cable and instrumentation cables

Rubber cable



Production Base

Strict Quality Test  (Test Resistence / Test Eccentricity / Test Pull Force)
Certificates
Trade Shows

Cooperation Partner





Customer Visit



International Exhibitions



Our Team



Packaging & Shipping

Packaging & Shipping

Contact us

Why choose us?

1.18 years manufacturing experience

2.Professional international trade team

3.Delivery on time

4.Factory low price and high quality based on advanced technology and high work efficiency
